40W Explosion Proof Led Industrial Light Specifications:
For Type A light there is one cable entry on the side of each Ex e chamber, which is protected by stopping plugs with protection level no less than Ex e llC Db / Ex tb lllC db product or clamp nut type cable entry which has rubber sealing. For Type B light, there is one cable entry on the side of each Ex e chamber which is protected by stopping plugs with protection level no less than Ex e llC Db. Ex tb iiiC Db product, and there is one more cable entry with compression nut and sealing ring on the top left side (illuminat replacing side) for explosion-protected junction box or emergency power source.
|
Model/type |
BC5401-L2×20 40W (Others on special order) |
BC5401-Y2×28, 14 (Special Order) |
|
Light source |
T8 Led Tube (Two Terminal Power Supply) |
T5 Fluorescent Tube (With T8 Bracket) |
|
Input voltage (V) |
AC 90~264V |
AC 220~240V, AC110V |
|
Rated voltage (V) |
AC110V, AC120V, AC127V, AC220V, AC230V, AC240V |
AC110V, AC220V, AC230V, AC240V |
|
Rated frequency(Hz) |
50/60 |
50/60 |
|
Rate power(W) |
2×20W LED tubes (Others available special order) |
2×28, 2×14 (Special Order) |
|
Light efficiency(lm/W) |
＞90 |
＞70 |
|
Color temperature(K) |
4000K (3000K,5000K is available) |
4000 |
|
Color rendering index (Ra) |
＞70 |
＞70 |
|
Service life (h) |
＞50000 |
＞20000 |
|
Ex marking |
Ⅱ2GD Ex de ⅡC T6 Gb Ex tb IIIC T80℃ Db IP66 Zone 1, Zone 2 (CL 1, DIV 1 & DIV 2) Gases Zone 21, Zone 22 (CL2, DIV 1 & DIV 2) Dusts
|
Ⅱ2GD Ex deⅡC T6 Gb Ex tb ⅢC T80℃Db IP66 |
|
Ingress protection |
IP66 |
IP66 |
|
Total harmonic current |
＜15% |
＜15% |
|
Weight(kg) |
11 |
7.5 |
|
Installation angle |
360° |
360° |
|
CSA of lead |
No less than 1.5mm2 |
No less than 1.5mm2 |
|
Cable Entry |
ф10-ф14 cable(M25*1.5,NPT3/4〞or G3/4〞) |
|
Also available Additional LED,40W Explosion Proof LED industrial light and Fluorescent. Please call for additional information.
Hazardous Location Lights: This category features HID & LED Drop Lights, Hand Lights, Portable Explosion Proof Lights, and other intrinsically safe lighting products. These lights are used in areas where petrochemical or dust particles have the potential to exist and the possibility of ignition is possible. Explosion proof lighting is rated Class 1, Division 1/2 or Class 2, Division 1/2 as specified by UL standards. These areas include offshore lights, rig lights, spray booths, cleaning vessels, fuel cells, plant turn around, marine work areas, grain storage, dust, or munitions.
The Xenide AEX20-EP HID searchlight is rated for Class 1, Division 1&2 applications. and is a powerful hid spotlight that can be used in a variety of industrial applications such as inspection lighting, industrial UV inspection light, and leak detection.
